Can a 220-240v WiiU adapter be used at 110v?

Can a 220-240v WiiU adapter be used at 110v? - Tin vessels and metal bucket with milk placed near bike leaned on shabby rusty wall

I have a Wii-U brought in South America (Chile) where the wall output is 240v. The Wii-U input voltage say's to be "220-240v", searching throughout the internet it says that US adapters (110v) works fine on 240v.

Actually I'm in México, and I came with my Wii-U, but I could not find anything that say's that I can safely plug in my Wii-U.



Best Answer

Disclaimer: The following answer is purely speculative, and intended for informational purposes only. Should you choose to try and use your WiiU power adapter at a voltage it is not rated for, I take no responsibility for the consequences (which, at the very least, likely include voiding the warranty, and might include damaging your adapter and/or your WiiU, or worse).

That disclaimer out of the way, let me note that that most modern switched-mode power adapters are designed for worldwide operation, i.e. to handle (at least) any input voltage from 110 VAC to 240 VAC at anywhere from 50 to 60 Hz. The reason for this is simply that it's easy to do, and it generally costs less to use a single standard worldwide adapter design for all regions than to design and build different power adapters for different parts of the world.

That said, usually such universal power adapters are also labeled with something like "input: 110–240 VAC". The fact that yours isn't might be due to several possible reasons:

  • The adapter might not actually be universal, and might break or just not work properly if given the wrong input voltage.

  • The adapter might be designed to handle any input voltage, but the manufacturer might use more restrictive labeling to cut down on testing and certification costs (the specific adapter-and-plug combination might've been intended only for 220–240 V markets, and might not have been specifically tested at 110 V) or warranty returns ("Oh, you used the adapter at the wrong voltage? Sorry, no warranty for you.").

  • The restrictive labeling could simply be a half-hearted attempt to limit "gray market" imports, and thus allow more variation in regional pricing (market segmentation).

  • Some combination of the above.

As you note, a quick Google search does turn up several sources claiming (and demonstrating) that, despite not being labeled as such, WiiU power adapters do work with any voltage. Granted, those sources are mostly about using the 110 V adapter at 220–240 V, rather than vice versa, but it really makes no sense for them to use a universal 110–240 V capable circuit for the "110 V" adapters, and not use the same circuit for all adapter types.

In any case, whereas using a non-universal power adapter at too high voltage might damage the adapter (or cause it to deliver overvoltage, damaging whatever it's supplying power for), using too low input voltage should, at worst, only cause the adapter to supply insufficient output voltage and/or current. This might cause the connected device (your WiiU) to fail to start up, or possibly to "brown out" and crash at high load, but it's rather unlikely to cause any permanent damage. (But do remember the disclaimer above!)

If you happen to have a multimeter lying around, one test you could do (at your own risk!) would be to plug the adapter in without connecting it to your Wii, and measure the voltage it delivers. Of course, this simple test doesn't really prove that your adapter can still maintain that voltage even under high current draw, but it should at least provide some reassurance about your power adapter's voltage tolerance, before you actually try using your WiiU with it.




Pictures about "Can a 220-240v WiiU adapter be used at 110v?"

Can a 220-240v WiiU adapter be used at 110v? - Spray Can on Gray Concrete
Can a 220-240v WiiU adapter be used at 110v? - Crop anonymous male sitting on stone bench with modern netbook and portable contemporary USB adapter
Can a 220-240v WiiU adapter be used at 110v? - Crop unrecognizable man cleaning computer system unit



Is Wii U dual voltage?

The Wii U's power supply is dual voltage (WUP002) while the Wii's power supply (RVL002) is not. Nintendo fan since 6 years of age.

Do the Wii and Wii U use the same power adapter?

The power brick is kind of big For the power supply, though, the Wii U comes with a proprietary A/C adapter (right) with a power brick that's significantly bigger than Nintendo's old system (left). That's to generate the 15 W of power that the new system needs, a slight increase from the 12 W needed for the Wii.

Does Wii U work on 220v?

I bought a Wii U in the US and I use it in Latin America where we use 220v. I plug the Wii U's AC adapter directly and it works. Same for the Wii U Gamepad AC adapter.

How many volts does a Wii use?

Buy your Wii in the U.S. and you'll get a large 120V-input power supply. Buy your Wii in Europe, and you'll get a large 220/210V power supply. Buy this, you'll get a smaller, lighter power supply that can effortlessly be used in both places.
