What is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs?

What is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs? - Like Printed on Brown Wooden Scrabble

I need to know the term for the kind of projection in games like Cadillacs and Dinosarus (a beat-´em up, shown below). The game uses a kind of pseudo-3D effect with techniques including isometric/axonometric projection, oblique projection, orthographic projection etc

What is the correct term for this behavior? Cavalier, cabinet, isometric, ...?

scenes of cadillacs and dinosaurs



Best Answer

I believe you are referring to the Parallax Scrolling technique.

Parallax scrolling is a technique in computer graphics and web design, where background images move by the camera slower than foreground images, creating an illusion of depth in a 2D scene and adding to the immersion.

Referring back to the screenshots in OP, this appears to be the technique in play. In order to create the 3D depth illusion a number of images are layered, with the bottom most images on top. Each layer will scroll at a different speed.

To simply the scenario, consider the game screen is split into 3 images:

  • The background
  • The ground
  • The foreground

The foreground is layered on top of the ground, and the ground is layered on top of the background. The background will scroll slower than the ground. The ground will scroll slower than the foreground.

Consider the screenshot in the bottom right.

The grass is in the foreground, and will move across the screen much faster than the dirt pathway as you walk left/right. Also, it will appear over the road and any characters in this plane. The mountains will scroll much slower in comparison to the dirt pathway. Additionally, anything in the plane of the dirt pathway such as characters will appear over the background.

I have used an example of 3 planes, but you will probably find the background has multiple planes itself (e.g. the clouds may move slower than the mountains). The main ground will also have its own plane system so that items lower down the axis will overlap items higher up. To complicate matters slightly, this is different from a character jumping (they will move higher up the screen but remain in the same axis/plane).

As mentioned in the comments, this technique is part of the 2.5D technique.

The Parallax Scrolling technique is used in a large number of games. Streets of Rage and Street Fighter spring to mind. It is also implemented into the SCUMM game engine (although this game engine additionally offers sprite scaling on the y-axis).




Pictures about "What is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs?"

What is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs? - Black woman showing thumb up to camera
What is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs? - Crop woman with opened notebook with inscriptions
What is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs? - Two Women Playing Golf



What are 2D and 3D games called?

Games which have 3D gameplay but 2D graphics is comes under in Isomertic Games. On the other hand those games that have 2D gameplay in 3D graphics are called 2.5D that means these games are between 2D and 3D.

What are 2D games called?

A platformer, or platform video game, is one that traditionally features two-dimensional graphics in which players control characters who jump or climb between different platforms on the screen. It's a subgenre of the Action category, which is one of the many different types of video games.

What are 2D video games?

Characteristics of 2D video games 2D games use flat graphics, called sprites, and don't have three-dimensional geometry. They're drawn to the screen as flat images, and the camera (orthographic camera) has no perspective.



Cadillacs and Dinosaurs - Hack ( Powerful Rainbow Edition 2019 ) Longplay




More answers regarding what is the name of the pseudo-3D view in 2D games like Cadillacs and Dinosaurs?

Answer 2

I don't think there can be an exact answer to this question because it does not appear that the artist(s) who drew the images adhered to a specific methodology. That said, you can still derive some projection methods used in certain areas.

Oblique Projection looks to be the most primarily used projection method. It is most clear in the top two images where the front of the building is an flat view while the top and sides follow a parallel angle. I measured the angle on the top edge of the building and the cracks of the roof tile to determine it had the expected approximate 30°/150° angles. I can't tell you if it is Cavalier or Cabinet because I don't know the measurements of the building.

See more examples that use this projection method

enter image description here

Perspective Projection is also used in some of these images, particularly the sixth and seventh image where even the foreground is drawn in a way that grows smaller in the distance. This drawing technique's use is more visibly evident from a screenshot from one of the later stages. See how the edges of the top plane of the stairs are not parallel, instead they converge towards a single point in the distance.

enter image description here

With this in mind I feel like you have to take a step back and accept that the artist(s) who drew these images did not have a strictly enforced projection method. They just drew the images so they looked good and provided some semblance of a 3D environment. A combination of that, parallax scrolling, and 3-Dimensional movement (left/right, in/out, jump/fall) gives the player the illusion that they are in a 3D environment.
