Diagnosis PS2 laser issue
I own a SCPH-39004 FAT PlayStation 2. It only reads one game (Gladiator), and for other games, shows a disk read error screen.
I tried to clean the lens, and adjust the lens height through two related screws. I also turned the lens potentiometeres clockwise a bit, but no luck.
I don't have oscilloscope, but a HIOKI 3256 multimeter.
How can I fix this problem?
Best Answer
Disk Read Errors are very common on older PS2s, especially the "fat" models. By the sounds of it, replacing the full optical block would probably be your best option for a guaranteed fix. There are many on eBay in the ~$20 range. In my opinion, this would be a much easier fix than diagnosing the laser/other components.
Pictures about "Diagnosis PS2 laser issue"
What does diagnosis on PS2 mean?
Diagnosis mode forces the laser to focus on the disc. It must be turned on every time you turn on your PS2, it doesn't save the setting.How do I run a diagnostic on my PS2?
To run the diagnostic tool, turn your PS2 on and go to the browser menu. Select the system menu. Then select "Diagnosis" from the submenu and press X. Press the "on" button and insert a disc.How do I fix my PS2 Slim laser?
Using a clean cotton bud, dip it in the isopropanol and gently wipe the lens in one smooth sweeping and twisting movement. Inspect the lens again with the magnifier. It should appear completely clean.Everything you should know about PS2 Phat Laser calibration
