Is there some way to use my Guitar Hero drum pedal on my PC?

I have a pedal from Guitar Hero World Tour, and I want to use it for push-to-talk in PC games. I don't want to have to connect the entire drum set, just the pedal. The pedal has a 3.5mm jack attached to it. Is there some way to use this on a computer and use a program like GlovePie to turn the pedal into a button?

controllers

Best Answer

I've messed around with the drum pedals for Rock Band and Guitar Hero before. They're just simple momentary switches with a really complex case. The 3.5mm jack is just an interface, the switch just shorts the two pins together.

What you'd need to do is convert that switch to something the PC can recognize as an input. It might be possible to connect the 3.5mm connector to Line In and then run some software to convert the on/off signal to an input, but a quick Google search doesn't turn up anything useful there.

Ideally, though, you'd have the pedal show up as a USB Human Interface Device (HID). I'm not aware of any currently available adapters that can do this directly, but someone with electronics expertise could probably make it work with a microcontroller that has USB HID support. It would also be possible to salvage the logic out of an old HID device (controller, mouse, keyboard) and wire the pedal into one of the already-present switches.

If you don't have the requisite electronics expertise, I'd suggest just getting a commercially available USB HID foot pedal and ditching the one for the drum kit. (Or, y'know, save the drums for later when RB/GH release new games...)

Pictures about "Is there some way to use my Guitar Hero drum pedal on my PC?"

Is there some way to use my Guitar Hero drum pedal on my PC? - Crop male musician in tee shirt and jeans standing and playing red electric guitar with drums behind

Is there some way to use my Guitar Hero drum pedal on my PC? - Person Playing The Drums

Is there some way to use my Guitar Hero drum pedal on my PC? - Free stock photo of action, active, activity

Can you use Guitar Hero drums as a MIDI controller?

This bass pedal is designed to withstand your hardest kicks. Plug it in and continue rocking your way to Guitar Hero stardom. Works with Rock Band, Rock Band 2, Rock Band Beatles, Guitar Hero World Tour, Band Hero & Rock Band 3 drum sets for Xbox 360, PlayStation 3, PlayStation 2 and Nintendo Wii.

Will a Rock Band kick pedal work with Guitar Hero?

Star Power is gained the same as the guitars, by hitting all the star power notes in a star power sequence. To activate star power on a Guitar Hero drum kit, both the orange and yellow cymbals have to be hit at the same time. For Rock Band drums, both the blue and yellow pads have to be hit at the same time.
